Linear Position Sensors

UK:  +44 (0)1733 575200          Fax: +44 (0)1908 888775          sales@multisense-solutions.com
Welcome to...
Linear Potentiometers
Sizes ranging from 9.4mm to 19mm diameter, with standard stroke lengths ranging from 12.5mm to 450mm...
Proven 'Conductive Plastic' tracks with 'Multi Finger' contacts provide high accuracy, excellent linearity and reliability. Sealing option to IP67 and operating temperature ranges from -40C to +175C as standard...
Custom options are available. Bespoke sensors can be designed and manufactured to suit special applications...
9.4mm Linear Position Sensor
Model: MS-94 series
  • 9.4mm dia housing
  • Range 12.5mm to 175mm
  • IP54/65/67 sealing
  • Rod End Bearings / Pop Joints
  • Rugged Construction
  • >25 million cycles
  • Flange mount
  • Protective sleeve
13mm Linear Position Sensor
15mm Linear Position Sensor
Model: MS-13 series
Model: MS-15 series
  • 13mm dia housing
  • Range 25mm to 200mm
  • IP54/65/67 sealing
  • Rod End Bearings / Pop Joints
  • Rugged construction
  • >25 million cycles
  • Regulated outputs
  • Dual output
  • Protective sleeve
  • 15mm dia square housing
  • Range 100mm to 250mm
  • IP54/65/67 sealing
  • Rod End Bearings
  • Rugged construction
  • >25 million cycles
  • Dual output
  • Regulated outputs
19mm Linear Position Sensor
Model: MS-19 series
  • 19mm dia housing
  • Range 25mm to 450mm
  • IP54/65/67 sealing
  • Rod End Bearings
  • Rugged Construction
  • >25 million cycles
  • Dual output
  • Regulated outputs
  • Protective sleeve
©2018 Multisense Solutions Ltd
9.4mm Spring Return sensor
Model: MS-94SR series
  • 9.4mm dia housing
  • Range from 12.5mm to 75mm
  • IP54 or IP65 sealing
  • Flange mount
  • Body clamp
  • Protective sleeve
13mm Spring Return sensor
Model: MS-13SR series
  • 13mm dia housing
  • Range from 25mm to 75mm
  • IP54/65/67 sealing
  • Dual Output
  • Flange Mount
  • Regulated outputs
  • Protective Sleeve
19mm Spring Return sensor
Model: MS-19SR series
  • 19mm dia housing
  • Internal spring return
  • Range from 50 to 150mm
  • IP54/65
  • Flange Mount
  • Dual output
  • Regulated outputs
A wide range of custom options are available and we specialise in manufacturing bespoke sensors, tailored to suit the application.
Multisense Solutions Ltd, Unit 82 Papyrus Road, Werrington, Peterborough, Cambs. PE4 5BH, UK
Please contact us to discuss your requirements or application....
